The Gold EAGLE is designed to operate under extreme environmental conditions.

Gold Eagle servo drives operate from a DC power source in current, velocity, position and advanced position modes, in conjunction with a permanent-magnet synchronous brushless motor, DC brush motor, linear motor or voice coil.

The GOLD Eagle has the same control CORE as  the Gold Line of servo drives, the Gold Eagle is fully programmable with Elmo’s motion control language.

Mating Power Supply ELP-30.

Gold Eagle Highlights:

Gold Line core motion control technology

Advanced and extremely fast vector control algorithm (current loop bandwidth: 4 kHz)

Highly efficient, high bandwidth performance

Multiple communication options: CAT, CANopen, RS232, RS422 USB, Ethernet

Supports a wide variety of feedback: Incremental, Encoder, Resolver, Digital Halls, Analog Halls, Analog 1V ptp (Sin/Cos), Absolute Serial Encoders, Tachometer, Potentiometer

Advanced filtering and gain scheduling options for enhanced dynamic performance

Easily optimized set up and tuned using Elmo Application Studio (EAS) software tools

Supports PLC Source, PLC Sink and TTL I/O types

Complies  to the most severe Safety, EMC and environmental standards.
